How to distinguish the quality of uv lamps?

  1. Conventional high temperature and low intensity UV lamps, conventional high

temperature and low intensity UV lamps use domestic light-emitting electrodes

with low purity impurities and are filled with low purity luminous substances.

The UV lamp can only be started with high current, and the production process is

relatively simple and backward, and the production cost is also low. The produced

uv lamp has low luminous intensity, high luminous current, and high luminous

temperature, which causes the printed matter to be deformed by heat and can

not be overprinted, and can not dry UV ink and varnish at high speed, This type of

uv lamp is generally used in slow screen printing production with low overprint

requirements, and is not suitable for high-speed offset printing production

with high overprint requirements.

high-grade printing because of its fine technology and rich color. Offset printing has

strict requirements for the expansion and deformation of printing and for the adaptation

to high efficiency and high speed printing. The UV lamp for offset printing must reach

a photofixation temperature of no more than 50 ° C to prevent the expansion and

deformation of printing, and the photofixation speed must reach 8000 sheets/hour,

The imported offset low temperature and high speed uv lamp is a kind of high pressure

mercury lamp that uses high purity luminous electrode and is filled with high purity luminous

gas with accurate proportion. It is produced through high-end technology, with low working

current, low temperature and high intensity, which is more than 40% lower than that of

conventional UV lamp of the same specification, and the luminous intensity is more than

100% higher. The offset low temperature and high speed UV curing machine is equipped with

intelligent high-speed automatic paper receiving machine, which controls the UV curing

temperature of printed matter at 45 ° C, UV light fixation speed reaches more than 9000

sheets/hour, which meets the technological conditions of low temperature and high speed

for offset printing, and is widely used in large printing industries such as cigarette label

packaging printing, color printing packaging printing, etc.

  3. Special printing: imported UV lamps are widely used for screen printing, lithography,

letterpress printing, self-adhesive trademarks, metal nameplates, KT plates, glass, ceramics,

electronic parts, single-sided circuit boards and other special effects such as crystal ice,

frosting, crystal gemstones, seven-color embossed oil.

   4. Low temperature high intensity UV lamp, low temperature high intensity UV lamp is

a low current high intensity high pressure mercury lamp produced by high-end technology

manufacturing process using imported high-purity luminous electrode, filled with accurate

proportion of high-purity luminous substances, and used in combination with power supply

with corresponding matching parameters, which can emit 365nm low temperature high

intensity light suitable for UV ink curing and drying, The luminous intensity is more than

100% higher than the intensity parameter of the conventional high temperature and low

intensity UV lamp of the same power, so that the UV ink and UV varnish can be dried at high

speed. Moreover, due to the low luminous current, the heat of the lamp tube is reduced,

and the luminous temperature is more than 40% lower than that of the conventional UV lamp.

The low temperature and high intensity light drying effect can be achieved without water cooling.
